This hardtail trail bike has an aggressive geometry that allows for a fun and playful ride on the trails or for day trips. The Shimano EP6 drivetrain is powerful, lightweight, and quiet. When combined with the integrated 504W battery, you can travel up to 120km on a single charge. The bike features 150mm dropper post (or 170mm, depending on frame size), making it ideal for off-road adventures. The 29" wheels provide plenty of speed for longer rides on less challenging terrain.

Features

• The Trail Ultimate frame geometry provides maximum control on the trail
• The Shimano EP6 drive system has 85 Nm of torque and a range of up to 120 km
• The colour display features Bluetooth technology for customising the motor settings using a mobile phone
• The RST Vibe AIR TNL-F fork has a travel of 140 mm

Base Info

• E-System: SHIMANO E-Bike system, Auto Shift compatible, Boost 400%, Trail 180%, Eco 60%, Peak output 500W
• Distance: 120km
• Max Torque: 85Nm/400%
• Weight: 23.8kg

E-Bike Parts

• Motor: SHIMANO STEPS EP600, 36V, 250W, 85Nm, Auto Shift compatible
• Charger: DARFON 4A Smart Plus charger
• Battery: DARFON, 36V, 504 Wh, integrated
• Display: SHIMANO SC-EM800, Clamp band
• Switch: SHIMANO EM800

Frameset

• Alloy Al-6061 T6 Custom tubing, Smooth Welding, Trail Ultimate Geometry, Shark Spine EVO 29er&27.5+, SHIMANO STEPS DU hanger, 2nd Gen. Battery Integration, BOOST 148x12, Post Mount, Replaceable RD Hanger, Inner Cable Routing, Adjust. seatpost ready
• Suspension Fork: RST Vibe, Tapered, Air, 140mm travel
• Headset: ACROS ZS44/EC49
• Suspension Travel Front: 140mm

Drivetrain

• Gear Range: 1x8, 12-46, 383%
• Shifters: microSHIFT ACOLYTE SL-M7180-R, 8-speed
• Rear Derailleur: microSHIFT ACOLYTE RD-M5185M
• Crankset: SHIMANO EM600, 170MM
• Chainring:34T
• Cassette: microSHIFT ACOLYTE CS-H083, 12-46T
• Chain: KMC e8S

Braking system

• Brakes: CLARKS CLOUT+, oversize piston, hydraulic disc brake
• Rotors: CLARKS CL 180

Wheels

• Front Hub: SHIMANO HB-MT400-B, 32H, CENTER LOCK, 15x110mm THRU Type AXLE
• Rear Hub: SHIMANO FH-MT400-B, 32H, CENTER LOCK, 12x148mm THRU Type AXLE
• Rims: Stars J30D, 32H
• Tyres: WTB Ranger Comp, 29x2.30
• Spokes: Sapim Leader, Stainless Black with secure lock nipples

Cockpit

• Stem: ONE1 TDS-ALD606 Alloy, 35mm, 0 Degrees
• Handlebar: ONE1 Alloy, 9 degree backsweep, 20mm rise, 760mm, 35mm
• Grips: Velo ergo

Parts

• Saddle: WTB Volt Sport
• Seatpost: ONE1 Alloy, MT171, dropper post 170mm, 30.9mm

Please Note: Bike Specification May Be Subject To Change Without Notice
